Pallet & Freight Dimensioning — Automated
CubiQ X, XL, and DTPS automate dimensional capture for pallets, oversized freight, and drive-through dock loads — eliminating DIM weight disputes, accelerating inbound processing, and keeping every shipment audit-ready.
Tell us about your operation — we'll prepare a demo matched to your volume and system type.
🔒 Secure · No spam · Trusted by 250+ logistics operators
Designed for freight-scale efficiency
.png)
| Throughput | 120 pallet/hour |
| Measurement Time | < 2 seconds |
| Dimensions range | 12 in - 79 in per edge |
| Accuracy | 99% |
| Structure | Fixed floor station |
| Integration | API — TMS, WMS, ERP |
_vector.svg)
| Throughput | 120 pallet/hour |
| Measurement Time | < 2 seconds |
| Dimensions range | 16 in - 118 in per edge |
| Accuracy | 99% |
| Structure | Station - extended frame |
| Integration | API — TMS, WMS, ERP |
_vector.svg)
.avif)
| Throughput | 250 pallet/hour |
| Measurement Time | < 2 second in transit |
| Dimensions range | 19 in - 118 in per edge |
| Accuracy | 99% |
| Mode | Drive-through |
| Integration | API — TMS, WMS, ERP |
Manual freight dimensioning at the dock is costing you more than you think.
01
Manual pallet measurements are inconsistent. Without certified dimensional data, every dispute with a shipper or carrier is a loss you cannot defend — and it compounds across every load.
02
Bulky pallets generate more chargeable weight than what gets billed when dimensions aren't captured at intake. Every underbilled load, every day, is direct revenue leakage.
03
Every pallet that needs to be measured manually stops your team. In high-volume docks, this multiplies into hours of lost throughput per shift.
Estimated returns based on your settings.
Monthly Benefit
Anual Benefit
SYSTEM CAPACITY (pkgs/hr)
Estimated ROI
Return on Investment (Payback) achieved in Month 0
Our team of engineers can perform a customized technical assessment to validate these savings at your specific distribution center.
Schedule technical evaluationThe Solution
CubiQ offers two automated sortation systems designed for different throughput requirements. Both integrate dimensioning, barcode reading, OCR, and rules-based routing in a single footprint — connected to your existing WMS or TMS.
Place the pallet in the scan zone or drive through the DTPS portal. Capture begins automatically — no manual triggers, no forklift stops.
Every measurement is timestamped, linked to shipment ID and dock operator. Full audit trail, export-ready for compliance or billing review.
DIM weight and actual weight are compared automatically. The correct chargeable weight is sent to your billing or cargo platform — zero manual steps.
Every oversized, lightweight pallet is billed at the correct chargeable weight. Most freight operations recover their full investment within 90 days through improved billing accuracy.
Every pallet measurement is logged, timestamped, and linked to the shipment record. You have certified, defensible data for every charge — disputes drop to near zero.
The DTPS24 captures dimensions as the forklift moves through the portal — no stops, no delays, no workflow disruption. Full dock throughput maintained at all times.
Air cargo dimensional weight at the 1:6000 factor is computed per IATA standard and pushed to your cargo platform. Always audit-ready, always compliant.
CubiQ ONE is deployed across multiple logistics verticals worldwide
CubiQ X: Accurate measurement of standard pallets.
CubiQ XL: Upgraded with a higher-power camera for oversized freight andblack stretch-wrapped items.
CubiQ DTPS: keeping forklift movement continuous without stopping. Non-stoppallet scanning
Yes. All three systems connect via REST API to major TMS, WMS, ERP, and air cargo platforms. Our integration team manages the full connection as part of the onboarding process.
The DTPS uses a multi-sensor portal that measures dimensions, weight, and reads barcodes as the forklift travels through at normal speed. No pause, no manual trigger — data is recorded and logged in under 1 second of transit.
Most freight operations recover their investment within 90 days through recovered DIM weight revenue and eliminated billing disputes. We can model your specific dock volume's ROI during the demo.
See exactly how much DIM weight revenue your freight operation is leaving at the dock. Free 30-minute technical demo — no commitment.
